Triac LED Dimming Driver 45W 12V (Constant Voltage)

The Triac LED Dimming Driver provides the required dim level for 12V LED strip lighting systems. Designed for ultimate flexibility, they allow users to easily add their own personal touch to illumination settings.

Simple easy wiring direct to any type of standard Leading or Trailing edge dimmer switch, no need for an expensive interface controller for most Home Automation Systems.

This new high quality triac dimmable driver controls 12V LED strip with smooth consistent dimming, free of flicker and lifespan up to 50,000 hours.

Recommended load of 30W - 45W

Specification

• Supply power input: 170~265V AC 50/60Hz
• Output wattage: 45W
• Output voltage: 12V DC
• Output current Max: 1.87A
• Dimming range: 5-100%
• Short circuit: Yes
• Overload protection: Yes
• 1.0kv surge protection: Yes
• Power factor: 0.90
• Efficiency: >85%
• Class: 2
• CE: Yes
• RoHS: Yes
• EMC & Safety compliance: EN61000-3-3, EN55015, EN61547
