Micro Switch 1576 Plastic

Code: MICRO SWI 1576

£8.40£10.50 Save 20%

In stock (9)

The Micro Switch 1576 is designed to be used in LED Extrusion profiles and dedicated for switching LED Tape on/off with the use of a button. The bottom of the Micro switch is fitted with sticky tape to provide secure mounting and additionally cools down the switch when mounted into an extrusion. It is ideally suited to be mounted into extrusions especially (but not only) under cabinets, shelves as well as well in sconces , portable LED lamps, desks lamps and floor lamps.

Maximum Current: 4A, 48W/12V, 98W/24V

Standby Power Consumption: 0.0003W/12V, 0.0006W/24V

Operational Temperature Range: -20°C to +55°C

Caution
  • Do not bend the base of the switch as it may damage the device.
  • Switching the main power on/off will cause the lit LED fixtures operated by the proximity switch to be turned off.
  • When mounting Micro Switch into extrusions 11 mm deep, the MW base must be used along with MW end caps - see linked products
Depth
9mm
Length
43mm
Width
11mm
Amperage
4A
Voltage
12-24V DC
Construction
Plastic
