Wise Dim Leading Edge Receiver 4 Channel 4 x 700W

The Wise Dim Leading Edge Kit is a 2800W 240V dimmer that contains four independent 700W dimmer channels and is controlled by wireless switches. It can dim incandescent, mains halogen and low voltage halogen. Any circuit can be changed from dimming to switching with the use of a dipswitch. This allows non-dimmable fittings such as fluorescents and LEDs to also be operated.

Please note the following:

• It is not recommended for use with dimmable LED and compact fluorescent lamps
• This box cannot be scene programmed
• It is not compatible with WISE INTENSE3 and WISE INTENSE6 transmitter switches

This product can be programmed in 4 different ways using our wireless switches:

Option A - Dimming Programming
Programming a 1 button switch gives you on/off with a quick press and dimming up and down while holding the switch. Lights will always turn on at the last dimmed level.

Option B - Two Button Switching ON/OFF
Programming a 2 button switch gives you ON and OFF on two separate buttons for one circuit. Please note, programming a circuit in this way will result in the circuit being unable to dim.

Option C - Master ON/OFF
Programming a 2 button switch gives you ON and OFF on two separate buttons for all four circuits. Please note, programming circuits in this way will result in all circuits being unable to dim.

Option D - PIR Sensor
Programming a Wise PIR Radio Sensor gives you ON and OFF on one circuit or all four circuits depending on if Option B or Option c is used. Please note, programming circuit(s) in this way will result in all circuits being unable to dim.

Wise Switches / Remotes

The main 4 buttons from our 7 button wireless wall mounted switch will operate the 4 circuits. The other three buttons perform the functions 2 circuits on, 4 circuits on, and all the circuits off. These three buttons allows the user basic scene setting capabilities. Each circuit on the Wise Dim is fused individually with a 3.15 amp fuse to protect all the circuits from overloading.
