Toroidal Transformer 50W 24V AC
Code: ALV050 24V
Archived — unavailable to order
This product has been discontinued and is no longer available to buy.
The ALV050 24V is a coil tranformer which is fully dimmable using transformer rated or inductive dimmers.
The transformer is toroidally wound with separate secondary windings thus giving each lamp its own fused output.
All transformers are fitted with self resetting bi-metallic thermal cut-outs to stop the mains supply if the temperature of the windings reaches 130°C. Input and output connections are via cables or terminal blocks. For safety, all transformers are encapsulated inside flame retardant housings using epoxy resin.
Compact sizes, low weights and well laid out wiring decks aid easy installation.
- Dimmable
- Yes
- Transformer Diameter
- 63mm
- Transformer Height
- 90mm
- Maximum Wattage
- 50W
- Minimum Wattage
- 10W
- Transformer
- Toroidal
- Voltage
- 24V AC
- Colour
- Black
- Construction
- Plastic
Replacement product
This product has been replaced by the following.
