QuietAir Basic Switching Extractor Fan 100mm 4 Inch 240V 147mm 5W - 9W

The Quiet Air Basic Switching Axial Fan combines contemporary design with ultra low noise levels and outstanding energy efficiency. It is designed to provide extraction levels in bathrooms and toilets that exceed the requirements of the latest buildings regulations.

As the name suggests, the QuietAir fan is eceptionally quiet with noise levels as low as 25dB(A). Its ECO start function means it is only activated when needed reducing the amount of energy used and therefore saving money. Not only is it discreet on the eye and ear, this fan is also discreet in its impact on the environment. With two speed option, The QuietAir fan consumes 5W or 9W of power.

Specifications

• Awarded QuietMark by Noise Abatement Society
• Extremely quiet, 25 dB(A) (5W) or 30 dB(A) (9W)
• Duct Diameter: 10mm
• Long-life ball bearings with approx. 40,000 hours life
• Two speed options, 21 l/s (5W) and 25 l/s (9W)
• Basic switching (two speed options)
• High efficiency impeller delivers up to 16.6 l/s through 12m of rigid ducting, including 90 degree bends
• Use in wet zone 1 when protected by an RCD and installed in accordance with latest IEE wiring regulations
• Integral flow straightener and back draught flap
• Low specific fan power for SAP assessments
• Clip-on cover for ease of cleaning
• Complies with latest Building Regulations Approved Document F
• Airflow 20.8/25 l/s
• Airflow @ 31Pa, 16.6 l/s
• Axial high efficiency impeller
• Wall/ceiling mounting
• Sound pressure 25 for 5W / 30 for 9W dB(A) @ 3m
• Power 5/9 watts
• SFP 0.24 w/l/s
• Rating IP45
• Max. ambient temperature 40 degree
